网络-交换机常见的故障及诊断方法

1.Fan faulty

  1）error log

I 08/25/23 04:13:57 00070 chassis: Fan OK: Fan: 1  Failures: 235

W 08/25/23 04:14:16 00070 chassis: Fan failure: Fan: 1  Failures: 236

  2）check the status of fan

switch# display fan

Fan  1 State: Fan Failed

Fan  2 State: Fan Failed

Fan  3 State: Fan Failed

  3）replace the hardware of fan

2.Power supply faulty

  1)error log

Power supply on switch is malfunctioning

  2)check the status of power

switch#show environment power
SW  PID                 Serial#     Status           Sys Pwr  PoE Pwr  Watts
--  ------------------  ----------  ---------------  -------  -------  -----
1A  PWR-C1-715WAC-P     DCC2716C31Z  OK              Good     Good     715
1B  Unknown             Unknown      Disabled        Bad      Bad      Unknown

  3)replace the hardware of power supply

3.High input error

  1)error log

High input error rate on interface Gi1/0/41. The inErrorRateState transitioned from NOMINAL to HIGH due to a measured value of 1.5009, which is between the configured low value of 0.001 and the configured high value of 100. The date and time of the measurement is 2023-08-26T20:51:00.383+0800.

  2)check the status of interface g1/0/41 if the input error is increasing

switch#show int g1/0/41 | in error
     734167 input errors, 317143 CRC, 0 frame, 0 overrun, 0 ignored
     0 output errors, 0 collisions, 1 interface resets

  3)do TDR test if the issue caused in cable site

switch#test cable-diagnostics tdr int g1/0/41
TDR test started on interface Gi1/0/41
A TDR test can take a few seconds to run on an interface
Use 'show cable-diagnostics tdr' to read the TDR results.

switch#show cable-diagnostics tdr int g1/0/41
TDR test last run on: August 30 07:10:32

Interface Speed Local pair Pair length        Remote pair Pair status
--------- ----- ---------- ------------------ ----------- --------------------
Gi1/0/41  1000M Pair A     64   +/- 10 meters Pair A      Normal
                Pair B     64   +/- 10 meters Pair B      Open
                Pair C     64   +/- 10 meters Pair C      Short
                Pair D     64   +/- 10 meters Pair D      Normal

  4)replace the cable int g1/0/41
